Features
Specifications
| Applicable fiber |
MMF(ITU-G651),SMF(ITU-G652), NZDS(ITU-G655),DS(ITU-G653) |
| PM fiber |
Panda fiber and other type PMF |
|
Cladding diameter |
80～150µm |
|
Coating diameter |
160～900µm |
|
Typical splice loss |
SMF:0.02dB MMF:0.01dB NZDS,DS:0.03dB,PMF 0.05dB |
|
Extinction ratio |
32dB(PANDA) |
|
Cleaved length |
10～16mm（coating diameter＜250um）; 16mm（coating diameter:250-1000um） |
|
Alignment method |
Profile and Endface alignment |
|
Splicing program |
40 groups |
|
Heating program |
20group; Automatic heating |
|
Operation mode |
Manual/ Automatic |
|
Typical splice time |
Unpolarized fiber: 15seconds; PM Fiber:45seconds |
|
Typical heating time |
30 seconds for 60mm and 40mm shrinkable sleeves |
|
Fiber Identification |
Automatically Identify SMF,MMF,NZDS,DS,PANDA PMF |
|
Fiber magnification |
180X (X or Y view), 90X (X and Y view) |
|
Viewing display |
Dual high sensitivity camera, 5 inch 800*480 LCD Monitor |
|
Data storage |
4000 groups data records |
|
Tension test |
1.8～2.25N |
|
Interface |
GUI menu interface, easy for operation |
|
Power supply |
Adaptor, input: AC100-240V(50/60HZ),output: DC11-13.5V |
|
Terminals |
USB 2.0 port, for software upgrading, records exporting |
|
Operating condition |
0 ~ 40℃ Not frosted |
|
Dimension/Weight |
260mm(W)×202mm(D)×170mm(H) /5.1kg（incuding battery） |
