3MP Full HD15M IR 360 Degree View Angle WDR Fisheye Network Camera Smart IPC IP Camera Support Heat Map PTZ
Features
- 1/3" progressive scan CMOS
- support Heat Map
- 3 mega-pixel image sensor
- Up to 1536 x 1536 resolution, 30fps
- 360° panoramic view
- Multiple viewing modes
- Virtual PTZ
- Up to 15m IR range
- Bulit-in microphone and speaker
- IP66, IK10 vandal proof(Option)
- Support 1-ch audio I/O, 1-ch alarm I/O and 1-ch RS-485 interface (Option)
Specifications
| Item |
3MP Fisheye Network Camera |
| Style |
Box Camera |
| High Definition |
1080P(Full-HD) |
| Connectivity |
IP/Network Wired |
| Supported Operating Systems |
Windows 98,Windows XP,Windows Vista,Windows 7,Mac os,Windows 8 |
| Sensor |
CMOS |
| Technology |
Infrared |
| Supported Mobile Systems |
iPhone OS,Symbian,Windows Mobile,Android |
| Power Consumption(W) |
12W MAX |
| Alarm Action |
FTP Photo,Email Photo |
| Power Supply(V) |
DC12V / PoE(802.3at) |
| Network Interface |
RJ-45 10/100Mb Ethernet Slot |
| Dimensions (L x W x D)(mm) |
Dia 164*152.8*43.8 |
| IR Distance(m) |
15M |
| Video Compression Format |
MJPEG,H.264 |
| Viewing Angle (Degree) |
360 Degree |
| Minimum Illumination(Lux) |
0.1 Lux @(F1.2,AGC ON), 0.28Lux @ (F2.0,AGC ON ), 0 lux with IR |
| Lens (mm) |
1.19mm, F2.0 Angle of view: 180°(wall mount), 360°(ceiling mount) |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Day& Night |
IR cut filter with auto switch |
| Digital noise reduction |
3D DNR |
| Max. Image Resolution |
2048*1536 |
| Weight |
1400g |
15M
